Higher power Lower LCOE 800W Solar Panel PV Module STELLAR 2N+78 Dual-Glass 770W-805W
| Product Specification | |
| Bifacial Factor | 80±5% |
| Cell Type | N-Type ABC |
| Glass | Dual glass, 2.0 + 2.0mm coated semi tempered glass |
| Frame | Anodized aluminum |
| Cable | 4mm²(IEC) 12AWG(UL)+400mm, -200mm or Customized Length |
| No. of Cells | 156(6*26) |
| Junction Box | IP68, 3 bypass diodes |
| Connector | MC4 Compatible |
| Weight | 39.8kg±3% |
| Dimension | 2465*1303*33mm |
| Package Detail | 33pcs per pallet / 132pcs per 20'GP / 594pcs per 40'HC |
| Temperature Ratings (STC) | |
| Temperature Coefficient of Isc | + 0.05%/ °C |
| Temperature Coefficient of Voc | - 0.22%/ °C |
| Temperature Coefficient of Pmax | - 0.26%/ °C |
| Installation Guide | |
| Operation Temperature | -40℃ - +70℃ |
| Maximum Series Fuse Rating | 30A |
| Protection Class | Class Ⅱ |
| Voc and Isc Tolerance | ±3% |
| Maximum System Voltage | DC1500V |
| Maximum Static Loading | Front 5400Pa Back 2400Pa |
| Hail Test | 25 mm diameter hail at 23 m/s |
| Fire Rating | IEC Class A |
|
Electrical Characteristics （ STC: AM1.5 1000W/m² 25℃ NOCT: AM1.5 800W/m² 20℃ 1m/s） |
||||||||||||||||
|
Module Type |
AIKO-A770-GRH78Dw |
AIKO-A775-GRH78Dw |
AIKO-A780-GRH78Dw |
AIKO-A785-GRH78Dw |
AIKO-A790-GRH78Dw |
AIKO-A795-GRH78Dw |
AIKO-A800-GRH78Dw |
AIKO-A805-GRH78Dw |
||||||||
|
TestConditions |
STC |
NOCT |
STC |
NOCT |
STC |
NOCT |
STC |
NOCT |
STC |
NOCT |
STC |
NOCT |
STC |
NOCT |
STC |
NOCT |
|
Pmax [W] |
770 |
584 |
775 |
588 |
780 |
592 |
785 |
595 |
790 |
599 |
795 |
603 |
800 |
607 |
805 |
610 |
|
Voc [V] |
58.72 |
55.68 |
58.82 |
55.77 |
58.92 |
55.87 |
59.02 |
55.96 |
59.12 |
56.05 |
59.22 |
56.15 |
59.32 |
56.24 |
59.42 |
56.34 |
|
Vmp [V] |
48.77 |
46.36 |
48.87 |
46.46 |
48.97 |
46.55 |
49.07 |
46.65 |
49.17 |
46.74 |
49.27 |
46.84 |
49.36 |
46.93 |
49.46 |
47.03 |
|
Isc [A] |
16.64 |
13.4 |
16.71 |
13.46 |
16.78 |
13.53 |
16.85 |
13.59 |
16.92 |
13.66 |
16.99 |
13.72 |
17.06 |
13.78 |
17.13 |
13.85 |
|
Imp [A] |
15.79 |
12.6 |
15.86 |
12.65 |
15.93 |
12.71 |
16.00 |
12.76 |
16.07 |
12.82 |
16.14 |
12.87 |
16.21 |
12.93 |
16.28 |
12.98 |
|
Module Efficiency |
24.0% |
24.1% |
24.3% |
24.4% |
24.6% |
24.8% |
24.9% |
25.1% |
||||||||
