High Quality HUAWEl DTSU666-H Single Phase Three Phase Smart Meter Featured Image
  • High Quality HUAWEl DTSU666-H Single Phase Three Phase Smart Meter
  • High Quality HUAWEl DTSU666-H Single Phase Three Phase Smart Meter
  • High Quality HUAWEl DTSU666-H Single Phase Three Phase Smart Meter
  • High Quality HUAWEl DTSU666-H Single Phase Three Phase Smart Meter
  • High Quality HUAWEl DTSU666-H Single Phase Three Phase Smart Meter
  • High Quality HUAWEl DTSU666-H Single Phase Three Phase Smart Meter

High Quality HUAWEl DTSU666-H Single Phase Three Phase Smart Meter

Short Description:

  •  High Accuracy – Class 1 precision, voltage ±0.5%, reliable current/power/energy measurement
  • ✅ RS485 Communication – Modbus-RTU protocol, easy integration with PV/storage monitoring systems
  • ✅ Flexible Ranges – Single-phase 100A / Three-phase 100A / Three-phase 250A for residential to C&I use
  • ✅ LCD Display – Easy parameter setting and real-time data check
  • ✅ Ultra-Low Power – Total consumption ≤1W, energy efficient
  • ✅ Wide Temperature Range – -40°C~70°C (3-phase models) for harsh environments
  • ✅ DIN35 Rail Mount – Compact size, simple installation

Product Detail

Product Tags

Rated Voltage 380 V Place of Origin Guangdong, China
Brand Name Huawei Model Number DTSU666-H
Maximum Current 176VDC-288VDC Color White
Gross weight per batch 1.500 kg Package size per batch 100X72X62.5 cm
详情图_2
详情图_4
详情图_5
