For high-end residential rooftop projects, homeowners often face a dilemma： high efficiency or roof aesthetics？ JinkoSolar‘s new 48QL6-DB and 48QL6-DV all-black dual-glass modules provide the perfect answer.
These modules cover 460W to 485W, built on the enhanced N-type TOPCon platform, with mass-production efficiency up to 24.27%. The all-black design – black frame, black backsheet (dual-glass naturally dark), black junction box – virtually disappears on dark roofs, making them a favorite among architects and premium homeowners.
Key Advantage 1： Dual-Glass, Ultra-High Load Capacity
Dual-glass construction not only enhances aesthetics but also delivers exceptional mechanical strength. Certified to withstand 6000Pa front-side load (≈300kg/m²) and 4000Pa rear-side load. Heavy snow or strong winds won‘t compromise performance. The dual-glass structure also eliminates moisture ingress, minimizing PID risk – ideal for coastal or high-humidity environments.
Key Advantage 2： N-type TOPCon for All-Weather Efficiency
Employing N-type TOPCon cells, these modules feature first-year degradation <1% and annual degradation of only 0.35%, retaining over 90% output after 30 years. The temperature coefficient is just -0.26%/°C, significantly outperforming PERC under high heat. Excellent low-light performance ensures power generation at dawn, dusk, and on cloudy days, extending effective generation hours daily.
Key Advantage 3： All-Black Aesthetics, Value Enhancement
Unlike standard modules with silver frames and white backsheets, the 48QL6-DB/DV blends seamlessly with dark roofs. For villas, luxury homes, or historically sensitive areas, all-black modules are often the only acceptable choice – and they can even increase property value.
Key Specifications
| Parameter | Value |
|---|---|
| Power range | 460W – 485W |
| Module efficiency | 23.02% – 24.27% |
| Cell type | N-type mono (192 cells, 48×4) |
| Dimensions | 1762×1134×30 mm |
| Weight | 24.4 kg |
| Dual glass | 2.0mm front + 2.0mm rear tempered |
| Junction box rating | IP68 |
| Max system voltage | 1500V DC |
| Front static load | 6000 Pa |
| Rear static load | 4000 Pa |
| First-year degradation | <1% |
| Temperature coefficient (Pmax) | -0.26%/°C |
Applications
- Premium residential rooftops (villas, self-built houses)
- Balcony PV (compact size, manageable weight for single-person installation)
- Historic or visually protected areas
- C&I rooftops requiring high reliability and load capacity
Chasun Solar： Your Jinko All-Black Module Gold Agent
Chasun Solar, a JinkoSolar Gold Agent, supplies Grade-A 48QL6-DB and 48QL6-DV modules – all with positive power tolerance and full traceability. Paired with GEN3 microinverters and LiFePO4 storage, they form a complete residential solar+storage system. We offer free rooftop assessment, system design, and LCOE calculation – helping you achieve energy independence with elegance.
CTA： Contact us today for Jinko all-black module pricing and a custom residential solar+storage solution！
Post time: Apr-28-2026
