Jinko C&I ESS Product Outdoor All-in-one DC Energy Storage System 215kWh 314kWh Hybrid Commercial and Industrial ESS SUNGIGA JKS-261KLAA-125PLAB
Jinko 261 Liquid-Cooled Integrated Cabinet integrates battery modules, BMS, PCS and fire protectionequipment to offer a 1000V energy storage system solution for users. This system has a battery capacity of 261 kWh and can deliver up to 135(or 125）kW of power. The product is charactrized by its flexible deployment, safety and reliability, intelligent liquid cooling, and smart software.Its modular design can meet the needs of various application scenarios.
| HIGHLY INTEGRATED | RELIABLE AND SAFE | SMART LIQUID-COOLING | SMART SOFTWARE |
| o All-in-one design, integrating | o Intelligent monitoring ensure | o Non-uniformliquidcooling pipeline | o Supports remote upgrades |
| PCS for easy transportation and | battery system safety | design ,effectively reduces the | |
| flexible O&M | temperature difference between battery cells | ||
| o Flexible Multi-Unit Expansion: | o Integrated heating system for | o Multiple liquid cooling control | o Cloud-based monitoring and |
| Modular design, supporting | thermal safety and enhanced | modes,reduce system power | operation platform,supports |
| parallel operation of multiple units | performance and reliability | consumption | access for multiple devices |
| Battery Input | ||
| Battery Input | LFP 3.2V/314Ah | |
| Max. charge and discharge power | 0.5P | |
| Configuration of system | 1P260S | |
| Number of packs | 5 pcs | |
| Nominal energy | 261 kWh | |
| Rated voltage | 832V | |
| Nominal voltage range | 702V~936V | |
| Cooling concept | liquid cooling | |
| AC Output | ||
| Rated AC power | 135/125 kW | |
| Rated voltage | 400 Vac | |
| AC connection | 3P4W | |
| Rated frequency | 50 Hz | |
| THDi | <3% | |
| On/off Grid Connection | 12 units in series | |
| General Data | ||
| Environment temp | -30℃~55℃, derating > 50° C | |
| Environment humidity | ≤99%RH ,without condensation | |
| Operating altitude | ≤3000m | |
| Degree of protection | IP55 | |
| Fire suppression system | System Aerosol Gas extinguisher+ smoke detection+ temperature sensing + flammable gas detection（Optional） | |
| Anticorrosion grade | C3/C5(Optional) | |
| Communication | RS485/CAN/Ethernet | |
| Dimensions（W×D×H） | 1000x1400x2400 mm | |
