GROWATT Commercial & Industrial PV Inverter MAX 50-80KTL3 LV
Remotely shutdown function
All kinds of communication methods available
● ShineLink-X
● ShineWiFi-X/ShineLan-X/Shine4G-X
● ShineMaster
● SEM
Powerful free platforms for global customers
monitoring platform
With Growatt ShineWiFi-X connecting the Growatt inverter to WiFi, it is easier for owners to check their solar system status on cell phones or PC.
● 6 /7MPPTs, fusefree design
● High efficiency up to 99%
● One-click diagnosis
● String monitoring
● AC&DC type II SPD
● AFCI optional
Smart Monitoring Platform
| Datasheet | MAX 50KTL3 LV | MAX 60KTL3 LV | MAX 70KTL3 LV | MAX 80KTL3 LV |
| Input data (DC) | ||||
| Max. recommended PV power (for module STC) |
75000W | 90000W | 105000W | 120000W |
| Max.DC voltage | 1100V | |||
| Start voltiage | 250V | |||
| Nomindl voltage | 585V | 585V | 600V | 600V |
| MPPI voltage range | 200V-1000V | |||
| No. of MPP tackers | 6 | 6 | 7 | 7 |
| No. of PV stings per MPP tracker | 2 | |||
| Max input cument per MPP tacker | 26A | |||
| Max short-circuit curent per MPP Tracker |
32A | |||
| Output data (AC) | ||||
| AC nominal power | 50000W | 60000W | 70000W | 80000W |
| Max. AC apparent power | 55500VA | 66600VA | 77700VA | 88800VA |
| Nominal AC voltage(iange?) | 220V/380V,230V/400V [340-440V] | |||
| AC grid frequencytange?] | 50/60 Hz(45-55Hz/55-65 Hz) | |||
| Max. output curent | 80.5A | 96.6A | 112.7A | 128.8A |
| Adjustable power factor | 0.8leading ...0.8lagging | |||
| THDi | <3% | |||
| AC grid connection type | 3W+N+PE | |||
| Efficiency | ||||
| Max.efficiency | 98.8% | 98.8% | 99% | 99% |
| European efticiency | 98.4% | 98.4% | 98.5% | 98.5% |
| MPPT efficiency | 99.9% | |||
| Protection devices | ||||
| DC reverse polarity protection | Yes | |||
| DC switch | Yes | |||
| DC surge protection | Typell/ Typell | |||
| Insulation resistance monitoing | Yes | |||
| AC shor-circuit protection | Yes | |||
| Ground fault monioing | Yes | |||
| Gid monitoing | Yes | |||
| Anti-slanding protection | Yes | |||
| Residual cument monitoring unit | Yes | |||
| Sting monitoing | Yes | |||
| AFCl protection | Optional | |||
| General data | ||||
| Dimensions (W/H/D) | 860/600/300mm | |||
| Weight | 82kg | 82kg | 86kg | 86kg |
| Operating temperature range | -25℃..+60℃ | |||
| Self-consumption | <1W | |||
| Topology | Transformerless | |||
| Cooling | Smart air cooling | |||
| Protection degree | IP65 | |||
| Relative humidity | 0-100% | |||
| Alifude | 4000m | |||
| DC connection | H4/MC4(Optional) | |||
| AC connection | Cable gland+ OI terminal | |||
| Display | LEDNMIFI+APP | |||
| Interfaces: RS485/USB MiF i/RF/GPRS |
YesNes /Optional/Optional/Opional | |||
| Warnanty: 5 years / 10 years | Yes /Optional | |||
| CE,VDE0126,Greece, EN50438,EN50549-1,CIO/C11,UIE C 15-712,IEC62116,IEC61727,IEC 60068,IEC61683,CE10-21, CEIO-16,N4105, DRRG,G98/G99,G100,NRS 097-2-1,MEA,PEA,KSC8565 |
||||
*The AC voltage range and frequency range may vary depending on specific country grid standard.
Alispecificafions are subjecffo change wmournofice.
