Product
All-in-one Stacked Battery-5/16KWh
| TECHNICAL PARAMETER | ||
| Model | CW-S5KWh-48V | CW-S16KWh-48V |
| Energy storage battery pack | ||
| Rated capacity | 5120Wh | 16076Wh |
| Battery capacity | 100Ah | 314Ah |
| Battery voltage | 51.2V | 51.2V |
| Battery model | LifePo4 battery | LifePo4 battery |
| Protection measures | BMS | BMS |
| Maximum current | 100A | 100A |
| IP rating | 65 | 65 |
| Single group weight | 50KG | 110KG |
| Single set of size | 180*590*400 | 250*700*450 |
| Stacking number of layers | 1-8 | 1-6 |
| Communication connection | RS232,RS485,CAN | RS232,RS485,CAN |
| Product certification | UN38.3,MSDS,IEC | UN38.3,MSDS,IEC |
| Operating temperature | -10℃-60℃ | -10℃-60℃ |
| Charging and discharging times | ≥6000 cycles | ≥6000 cycles |
| Packaging materials | Carton | Carton |
| Installation method | Standing | Standing |
| MPPT Solar Generator | ||
| Output power | 6000W | 12000W |
| Output waveform | Sine wave | Sine wave |
| AC Output | 220VAC 230VAC,50/60HZ23.9A | 220VAC 230VAC,50/60HZ23.9A |
| PV Input current/lnput power | 27A/9000w | Using One MPPT:27A/9KW Using Two MPPTS:22.5A/Per MPPT, 15kW/Total |
| PV charge current | 120A | 160A |
| Solar input voltage | 60-450VDC | 60-450VDC |
| Temperature protection | -20℃-70℃ | -20C-70℃ |
| Package size | 180*590*400 | 250*700*450 |
| Product Weight | 25KG | 35KG |
| Warranty time | 2 years | 2 years |
