GROWATT Residential PV Inverter MIC 750-3300TL-X
Remotely shutdown function
All kinds of communication methods available
Shine WiFi-x
Shine4G-x
ShineLan-x
ShineLink-x
Powerful free platforms for global customers
Growatt Monitoring Platform
● Maximum efficiency of 97.6%
● Compact design
● Touch key& OLED display
● Flexible monitoring options
● AFCI optional
Primary Specification
|
Datasheet |
MIC750TL-X |
MIC1000TL-X |
MIC1500TL-X |
MIC2000TL-X |
MIC2500TL-X |
MIC3000TL-X |
MIC3300TL-X |
|
Input data (DC) |
|||||||
|
Max. recommended PV power (for module STC) |
1050W |
1400W |
2100W |
2800W |
3500W |
4200W |
4290W |
|
Max. DC voltage |
500V |
500V |
500V |
500V |
550V |
550V |
550V |
|
Start voltage |
50V |
50V |
50V |
50V |
80V |
80V |
80V |
|
Nominal voltage |
120V |
180V |
250V |
360V |
360V |
360V |
360V |
|
MPP voltage range |
50V-500V |
50V-500V |
50V-500V |
50V-500V |
65V-550V |
65V-550V |
65V-550V |
|
No. of MPP trackers |
1 |
||||||
|
No. of PV strings per MPP tracker |
1 |
||||||
|
Max. input current per MPP tracker |
13A |
||||||
|
Max. short-circuit current per MPP tracker |
16A |
||||||
|
Output data (AC) |
|||||||
|
AC nominal power |
750W |
1000W |
1500W |
2000W |
2500W |
3000W |
3300W |
|
Max. AC apparent power |
750VA |
1000VA |
1500VA |
2000VA |
2500VA |
3000VA |
3300VA |
|
Nominal AC voltage(range*) |
230V (180-280V) |
||||||
|
AC grid frequency(range*) |
50/ |
60 Hz (45-55Hz/55-65 |
Hz) |
||||
|
Max. output current |
3.6A |
4.8A |
7.1A |
9.5A |
11.9A |
14.3A |
14.3A |
|
Adjustable power factor |
0 |
8leading…0 .8laggin |
g |
||||
|
THDi |
<3% |
||||||
|
AC grid connection type Efficiency |
Single phase |
||||||
|
Max.efficiency |
97.4% |
97.4% |
97.4% |
97.4% |
97.6% |
97.6% |
97.6% |
|
European efficiency |
96.5% |
96.5% |
97.0% |
97.0% |
97.0% |
97. 1% |
97. 1% |
|
MPPT efficiency |
99.9% |
||||||
|
Protection devices |
|||||||
|
DC reverse polarity protection |
Yes |
||||||
|
DC switch |
Yes |
||||||
|
AC/DC surge protection |
Type III / Type III |
||||||
|
Insulation resistance monitoring |
Yes |
||||||
|
AC short-circuit protection |
Yes |
||||||
|
Ground fault monitoring |
Yes |
||||||
|
Grid monitoring |
Yes |
||||||
|
Anti-islanding protection |
Yes |
||||||
|
Residual-current monitoring unit |
Yes |
||||||
|
AFCI protection General data |
Optional |
||||||
|
Dimensions (W / H / D) |
274/254/138mm |
||||||
|
Weight |
6kg |
6kg |
6kg |
6kg |
6.2kg |
6.2kg |
6.2kg |
|
Operating temperature range |
–25°C . . . +60°C |
||||||
|
Nighttime power consumption |
< 0.5W |
||||||
|
Topology |
Transformerless |
||||||
|
Cooling |
Natural convection |
||||||
|
Protection degree |
IP65 |
||||||
|
Relative humidity |
0- 100% |
||||||
|
Altitude |
4000m |
||||||
|
DC connection |
H4/MC4(Optional) |
||||||
|
AC connection |
Connector |
||||||
|
Display |
OLED+LED/WIFI+APP |
||||||
|
Interfaces: RS485 / USB/Wi-Fi/ GPRS/ RF/LAN |
Yes/Yes/Optional/Optional/Optional /Optional |
||||||
|
Warranty: 5 years / 10 years |
Yes /Optional |
||||||
|
CE,AS4777, AS/NZS 3100, CEI 0-21, VDE-AR-N 4105, VDE 0126- 1- 1, UTE C 15-712- 1, EN50549, IEC 60068, IEC 61683, IEC 62116, IEC 61727, INMETRO, G98, C10/C11, UNE217001, UNE206007, PO12.2 |
|||||||
* The AC voltage and frequency range may vary depending on specific country grid standard .
All specifications are subject to change without notice .
